Configuring Layer 2 Multicast IGMP Snooping Configuration

User Guide

299

Figure 2-2 Configure IGMP Snooping for VLAN

Follow these steps to configure IGMP Snooping for a specific VLAN:

1) Enable IGMP Snooping for the VLAN, and configure the corresponding parameters.

VLAN ID Displays the VLAN ID.

IGMP Snooping

Status

Enable or disable IGMP Snooping for the VLAN.
