User Guide 308
Configuring Layer 2 Multicast IGMP Snooping Configuration
Step 5 ip igmp snooping vlan-config
vlan-id-list
report-suppression
(Optional) Enable the Report Suppression for the VLANs. By default, it is disabled.
When enabled, the switch will only forward the first IGMP report message for each multicast
group to the IGMP querier and suppress subsequent IGMP report messages for the same
multicast group during one query interval. This feature prevents duplicate report messages
from being sent to the IGMP querier.
vlan-id-list:
Specify the ID or the ID list of the VLAN(s).
Step 6 ip igmp snooping vlan-config
vlan-id-list
immediate-leave
(Optional) Enable the Fast Leave for the VLANs. By default, it is disabled. IGMPv1 does not
support fast leave.
Without Fast Leave, after a receiver sends an IGMP leave message to leave a multicast group,
the switch will forward the leave message to the Layer 3 device (the querier).
From the point of view of the querier, the port connecting to the switch is a member port of the
corresponding multicast group. After receiving the leave message from the switch, the querier
will send out a configured number (Last Member Query Count) of group-specific queries on
that port with a configured interval (Last Member Query Interval), and wait for IGMP group
membership reports. If there are other receivers connecting to the switch, they will response
to the queries before the Last Member Query Interval expires. If no reports are received
after the response time of the last query expires, the querier will remove the port from the
forwarding list of the corresponding multicast group.
That is, if there are other receivers connecting to the switch, the one sent leave message have
to wait until the port ages out from the switch’s forwarding list of the corresponding multicast
group (the maximum waiting time is decided by the Member Port Aging Time).
With Fast Leave enabled on a VLAN, the switch will remove the (Multicast Group, Port, VLAN)
entry from the multicast forwarding table before forwarding the leave message to the querier.
This helps to reduce bandwidth waste since the switch no longer sends the corresponding
multicast streams to the VLAN of the port as soon as the port receives a leave message from
the VLAN.
vlan-id-list:
Specify the ID or the ID list of the VLAN(s).
Step 7 ip igmp snooping vlan-config
vlan-id-list
rport interface { fastEthernet
port-list
|
gigabitEthernet
port-list
| ten-gigabitEthernet
port-list
| port-channel
lag-list
}
(Optional) Specify the static router ports for the VLANs. Static router ports do not age.
vlan-id-list:
Specify the ID or the ID list of the VLAN(s).
port-list
: The number or the list of the Ethernet port that need to be configured as static router
ports.
lag-list
: The ID or the list of the LAG that need to be configured as static router ports.
Step 8 ip igmp snooping vlan-config
vlan-id-list
router-ports-forbidden interface { fastEthernet
port-list
| gigabitEthernet
port-list
| ten-gigabitEthernet
port-list
| port-channel
lag-list
}
(Optional) Specify the ports to forbid them from being router ports in the VLANs.
vlan-id-list:
Specify the ID or the ID list of the VLAN(s).
port-list
: The number or the list of the Ethernet port that need to be forbidden from being
router ports.
lag-list
: The ID or the list of the LAG that need to be forbidden from being router ports.
