Accessing the Switch Web Interface Access
User Guide
9
4) Click to save the settings.
■ Configure the Default Gateway
The following example shows how to configure the switch’s gateway. By default, the switch
has no default gateway.
1) Go to page
L3 FEATURES > Static Routing > IPv4 Static Routing Config
. Click to
load the following page and configure the parameters related to the switch’s gateway.
Then click Create.
Figure 2-9 Configure the Default Gateway
Destination Specify the destination as 0.0.0.0.
Subnet Mask Specify the subnet mask as 0.0.0.0.
Next Hop Configure your desired default gateway as the next hop’s IP address.
Distance Specify the distance as 1.
2) Click to save the settings.
3) Check the routing table to verify the default gateway you configured. The entry marked
in red box displays the valid default gateway.
Figure 2-10 View the Default Gateway
