TP-Link T2600G Series User Manual

User Guide 408
Configuring Spanning Tree MSTP Configurations
■ Configuring Parameters on Ports in the Instance
Choose the menu L2 FEATURES > Spanning Tree > MSTP Instance > Instance Port
Config to load the following page.
Figure 3-5 Configuring Port Parameters in the Instance
Follow these steps to configure port parameters in the instance:
1) In the Instance Port Config section, select the desired instance ID.
Instance ID Select the ID number of the instance that you want to configure.
2) Configure port parameters in the desired instance.
UNIT Select the desired unit or LAGs for configuration.
Priority Specify the Priority for the port in the corresponding instance. The value
should be an integral multiple of 16, ranging from 0 to 240.
The port with lower value has the higher priority. When the root path of the
port is the same as other ports’, the switch will compare the port priorities
between these ports and select a root port with the highest priority.
Path Cost Enter the value of the path cost in the corresponding instance. The valid
values are from 0 to 2000000. The default setting is Auto, which means the
port calculates the external path cost automatically according to the port’s
link speed. The port with the lowest root path cost will be elected as the root
port of the switch.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
