User Guide 576
Configuring DHCP Service Configuration Examples
Figure 5-10 Creating the Static Routing Entry for VLAN 20
■ Configuring the VLANs on the Relay Agent
1) Choose the menu L2 FEATURES > VLAN > 802.1Q VLAN > VLAN Config and click
to load the following page. Create VLAN 10 for the Marketing department and
add port 1/0/1 as an untagged port to the VLAN.
Figure 5-11 Creating VLAN 10
