TP-Link T2600G Series User Manual

User Guide 642
Configuring QoS Class of Service Configuration
Step 4 For T2600G-28TS/T2600G-28MPS/T2600G-28SQ/T2600G-52TS:
show qos dscp-map interface [fastEthernet
port | gigabitEthernet port | ten-
gigabitEthernet
port | port-channel port-channel-id ]
Verify the DSCP to queue mappings of ports.
For T2600G-18TS:
show qos dscp-map
Verify the DSCP to queue mappings globally.
Step 5 For T2600G-28TS/T2600G-28MPS/T2600G-28SQ/T2600G-52TS:
show qos dscp-remap interface [fastEthernet
port | gigabitEthernet port | ten-
gigabitEthernet
port | port-channel port-channel-id ]
Verify the DSCP to DSCP mappings of the ports.
For T2600G-18TS:
show qos dscp-remap
Verify the DSCP to DSCP mappings globally.
Step 6 end
Return to privileged EXEC mode.
Step 8 copy running-config startup-config
Save the settings in the configuration file.
Note:
For T2600G-18TS, in Trust DSCP mode, non-IP packets will be added an 802.1p priority based on the
port to 802.1p mapping and will be forwarded according to the 802.1p to queue mapping.
The following example shows how to configure the trust mode of port 1/0/1 as dscp, map
802.1p priority 3 to TC4, map DSCP priority 1-3,5,7 to 802.1p priority 3, and configure to
map the original DSCP priority 9 to DSCP priority 5:
Switch#configure
Switch(config)#interface gigabitEthernet 1/0/1
Switch(config-if)#qos trust mode dscp
Switch(config-if)#exit
Switch(config)#qos cos-map 3 4
Switch(config)#interface gigabitEthernet 1/0/1
Switch(config-if)#qos dscp-map 1-3,5,7 3
Switch(config-if)#qos dscp-remap 9 5
Switch(config-if)#show qos trust interface gigabitEthernet 1/0/1

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
