TP-Link T2600G Series User Manual

User Guide 662
Configuring QoS Auto VoIP Configuration
Step 7 show auto-voip
Verify the global state of Auto VoIP.
Step 8 show auto-voip interface
Verify the Auto VoIP configuration information of ports.
Step 8 end
Return to privileged EXEC mode.
Step 9 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to set the interface mode as dot1p, specify the 802.1p
priority as 4, specify the DSCP priority as 10 and enable the CoS override mode for port
1/0/3:
Switch#configure
Switch(config)#auto-voip
Switch(config)#interface gigabitEthernet 1/0/3
Switch(config-if)#auto-voip dot1p 4
Switch(config-if)#auto-voip dscp 10
Switch(config-if)#auto-voip data priority untrust
Switch(config-if)#show auto-voip
Administrative Mode: Enabled
Switch(config-if)#show auto-voip interface
Interface.Gi1/0/1
Auto-VoIP Interface Mode. Disabled
Auto-VoIP COS Override. False
Auto-VoIP DSCP Value. 0
Auto-VoIP Port Status. Disabled
Interface.Gi1/0/2
Auto-VoIP Interface Mode. Disabled
Auto-VoIP COS Override. False
Auto-VoIP DSCP Value. 0
Auto-VoIP Port Status. Disabled

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
