User Guide 698
Configuring Access Security Access Security Configurations
■ When the MAC-based mode is selected, the following window will pop up.
Figure 2-3 Configuring Access Control Entry Based on MAC Address
Access
Interface
Select the interfaces where to apply the Access Control rule. If an interface is
unselected, all users can access the switch via it.
SNMP: A function to manage the network devices via NMS.
Telnet: A connection type for users to remote login.
SSH: A connection type based on SSH protocol.
HTTP: A connection type based on HTTP protocol.
HTTPS: A connection type based on SSL protocol.
Ping: A communication protocol to test the connection of the network.
MAC Address Enter the MAC address. Only the users with this MAC address can access the
switch via the specified interfaces.
■ When the Port-based mode is selected, the following window will pop up.
Figure 2-4 Configuring Access Control Entry Based on Port
