Configuring AAA AAA Configuration
User Guide
729
Step 5 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to add a RADIUS server on the switch. Set the IP address
of the server as 192.168.0.10, the authentication port as 1812, the shared key as 123456,
the timeout as 8 seconds and the retransmit number as 3.
Switch#configure
Switch(config)#radius-server host 192.168.0.10 auth-port 1812 timeout 8 retransmit 3
key 123456
Switch(config)#show radius-server
Server Ip Auth Port Acct Port Timeout Retransmit NAS Identifier
Shared key
192.168.0.10 1812 1813 5 2 000AEB132397 123456
Switch(config)#end
Switch#copy running-config startup-config
Adding TACACS+ Server
Follow these steps to add TACACS+ server on the switch:
Step 1 configure
Enter global configuration mode.
Step 2 tacacs-server host
ip-address
[ port
port-id
] [ timeout
time
] [ key { [ 0 ]
string
| 7
encrypted-string
} ]
Add the RADIUS server and configure the related parameters as needed.
host
ip-address
:
Enter the IP address of the server running the TACACS+ protocol.
port
port-id
:
Specify the TCP destination port on the TACACS+ server for authentication
requests. The default setting is 49.
timeout
time
:
Specify the time interval that the switch waits for the server to reply before
resending. The valid values are from 1 to 9 seconds and the default setting is 5 seconds.
key { [ 0 ]
string
| 7
encrypted-string
}: Specify the shared key. 0 and 7 represent the
encryption type. 0 indicates that an unencrypted key will follow. 7 indicates that a symmetric
encrypted key with a xed length will follow. By default, the encryption type is 0.
string
is the
shared key for the switch and the server, which contains 31 characters at most.
encrypted-
string
is a symmetric encrypted key with a fixed length, which you can copy from the
conguration le of another switch. The key or encrypted-key you congured here will be
displayed in the encrypted form.
Step 3 show tacacs-server
Verify the configuration of TACACS+ server.
