User Guide 800
Configuring ACL ACL Configuration
In the Packet Content Offset Profile Global Config section, configure the Chunk Offset.
Click Apply.
Chunk0 Offset/
Chunk1 Offset/
Chunk2 Offset/
Chunk3 Offset
Enter the offset of a chunk. Packet Content ACL analyzes and processes data
packets based on 4 chunk match conditions, and each chunk can specify a
user-defined 4-byte segment carried in the packet’s first 128 bytes. Offset 31
matches the 127, 128, 1, 2 bytes of the packet, offset 0 matches the 3,4,5,6
bytes of the packet, and so on, for the rest of the offset value.
Note:
All 4 chunks must be set at the same time.
In ACL Rules Table section, click and the following page will appear.
Figure 2-28 Configuring the Packet Content ACL Rule
