Configuring ACL ACL Configuration
User Guide
815
Step 2 access-list action
acl-id-or-name
rule
rule-id
Configure the policy actions for an ACL rule.
acl-id-or-name
: Enter the ID or name of the ACL.
rule-id
: Enter the ID of the ACL rule.
Step 3
redirect interface { fastEthernet
port
| gigabitEthernet
port
| ten-gigabitEthernet
port
}
(Optional) Define the policy to redirect the matched packets to the desired port.
port
: The destination port to which the packets will be redirected. The default is All.
s-mirror interface
{ fastEthernet
port
| gigabitEthernet
port
| ten-gigabitEthernet
port
}
(Optional) Define the policy to mirror the matched packets to the desired port.
port
: The destination port to which the packets will be mirrored.
s-condition rate
rate
burst
burst-size
osd { none | discard | remark dscp
dscp
}
(Optional) Define the policy to monitor the rate of the matched packets.
rate
: Specify a rate from 1 to 1000000 kbps.
burst-size
: Specify the number of bytes allowed in one second ranging from 1 to 128.
osd: Select either “none”, “discard” or “remark dscp” as the action to be taken for the packets
whose rate is beyond the specified rate. The default is None. When “remark dscp” is selected,
you also need to specify the DSCP value for the matched packets. The DSCP value ranges
from 0 to 63.
Note: Remark DSCP is not available for T2600G-18TS.
qos-remark [dscp
dscp
] [ priority
pri
] [ dot1p
pri
]
(Optional) Define the policy to remark priority for the matched packets.
dscp
: Specify the DSCP region for the data packets. The value ranges from 0 to 63.
priority
pri
: Specify the local priority for the data packets. The value ranges from 0 to 7.
dot1p
pri:
Specify the 802.1p priority for the data packets. The value ranges from 0 to 7.
Step 4 end
Return to privileged EXEC mode.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
Redirect the matched packets to port 1/0/4 for rule 1 of MAC ACL 10:
Switch#configure
Switch(config)#access-list action 10 rule 1
