Configuring IPv6 IMPB IPv6 IMPB

User Guide

881

Figure 1-1 Network Topology of ND Detection

Trusted

Port

Switch

Untrusted Port

Untrusted Port

Attacker

User A

Gateway

Internet

IPv6 Source Guard

IPv6 Source Guard is used to filter the IPv6 packets based on the IPv6-MAC Binding table.

Only the packets that match the binding rules are forwarded.
