YASKAWA DX100 Operator's Manual

6-43
155507-1CD
RE-CSO-A037
DX100
6 Convenient Functions
6.4 Parallel Shift Job Conversion Function
 Variables used in an individual shift
Example 1) When selecting P010 for a coordinated job with R1 + R2:
Use P010 for R1.
Use P011 for R2.
The system with multiple stations
NOTE
Be sure to use the variables of which numbers are
consecutive after the selected number. The variables of
which numbers are not consecutive are unable to be
selected.
P010
JOB R2
P011
JOB R1
283 of 554

YASKAWA DX100 Specifications

General

Programming Language	Inform III
Compatible Robots	Motoman robots
Operating Temperature	0-45°C
Humidity	20-80% RH (non-condensing)
Protection Class	IP20
Interface	Ethernet
Safety Standards	ANSI/RIA R15.06-1999
Pendant	Available
I/O Capacity	1024 inputs / 1024 outputs
Storage Temperature	-10-60°C
