7 External Memory Devices
7.2 Handling Data
Table 7-1: Data List (Sheet 1 of 2)
Data Classification File Name
(Saved Data)
Save Load
OPN EDIT MAN OPN EDIT MAN
8. ALL CMOS AREA ALCMSxx.HEX XXX
7. BATCH CMOS CMOSxx.HEX XX
3. BATCH USER MEMORY JOBxx.HEX X
1. JOB Single job JOBNAME.JBI X
Related job
(Job+Condition)
JOBNAME.JBR X
2 FILE/
GENERAL
DATA
Tool data TOOL.CND X
Weaving data WEAV.CND X
User coordinate data UFRAME.CND X
Variable data VAR.DAT X
Arc start condition data ARCSRT.CND X
Arc end condition data ARCEND.CND X
Welding condition
auxiliary data
ARCSUP.DAT X
Power source
characteristic data
WELDER.DAT X
Power source
characteristic definition
data
WELDUDEF.DAT X
Shock detection level
data
SHOCKLVL.CND X
Motor gun pressure
power data
SPRESS.CND X
Motor gun dry spot
pressure data
SPRESSCL.CND X
Spot gun characteristic
data
SGUN.DAT X
Spot welding power
source characteristic
data
SWELDER.DAT X
Short/Full open
position data
STROKE.DA
T X
Spot I/O allocation data SPOTIO.DAT X
Airgun condition data AIRGUN.DAT X
Spot welding condition
data
SPOTWELD.DAT X
Clearance data CLEARANCE.DAT X
Interference area file CUBEINTF.CND X
4. PARAMETER BATCH ALL.PRM XX
4. PARA-
METER
Robot matching
parameter
RC.PRM XX
System definition
parameter
SD.PRM XX
