User Guide 992
Configuring OAM Ethernet OAM Configurations
Step 3 ethernet-oam link-monitor frame-seconds [ threshold threshold ] [ window window ] [
notify {disable | enable}]
Configure the relevant parameters of Error Frame Period.
threshold : Specify the threshold of received error frame seconds within a specic period of
time. Valid values are from 1 to 900, and the default value is 1.
window : Specify the period time in 100ms, in which if the received errors exceed the
threshold, a link event will be generated. Valid values are from 100*100 to 9000*100 ms,
and the default value is 600*100 ms.
disable | enable :
Enable or disable the port to report the failure condition.
Step 4 show ethernet-oam configuration [ interface fastEthernet {
port | port-list } | interface
gigabitEthernet {
port | port-list } | ten-gigabitEthernet { port | port-list } ]
Verify the OAM configuration.
Step 5 end
Return to privileged EXEC mode.
Step 6 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to enable Error Frame Seconds notification and
configure the threshold as 1 and the window as 80000 ms (800*100 ms)on port 1/0/1:
Switch#configure
Switch(config)#interface gigabitEthernet 1/0/1
Switch(config-if)#ethernet-oam link-monitor frame-seconds threshold 1 window 800
notify enable
Switch(config-if)#show ethernet-oam configuration interface gigabitEthernet 1/0/1
Gi1/0/1
-----------------------------------------------------------
...
Frame Seconds Error
Notify State : Enabled
Window : 80000 milliseconds
Threshold : 1 Error Seconds
...
Switch(config-if)#end
Switch#copy running-config startup-config
