TP-Link T2600G Series User Manual

User Guide 1052
Notification Configurations
The following example shows how to configure the switch to enable IP-Change trap:
Switch#configure
Switch(config)#snmp-server traps ip change
Switch(config)#end
Switch#copy running-config startup-config
■ Enabling the SNMP PoE Traps Globally
Note:
Only T2600G-28MPS supports PoE traps.
Step 1 configure
Enter Global Configuration Mode.
Step 2 snmp-server traps power [over-max-pwr-budget | port-pwr-change | port-pwr-deny | port-
pwr-over-30w | port-pwr-overload | port-short-circuit | thermal-shutdown ]
Enable the PoE traps. The command without any parameter enables all PoE traps. By
default, all PoE traps are disabled.
over-max-pwr-budget: Triggered when the total power required by the connected PDs
exceeds the maximum power the PoE switch can supply.
port-pwr-change: Triggered when the total power required by the connected PDs exceeds
the maximum power the PoE switch can supply.
port-pwr-deny: Triggered when the switch powers off PDs on low-priority PoE ports. The
switch powers off them to ensure stable running of the other PDs when the total power
required by the connected PDs exceeds the system power limit.
port-pwr-over-30w: Triggered when the power required by the connected PD exceeds 30
watts.
port-pwr-overload: Triggered when the power required by the connected PD exceeds the
maximum power the port can supply.
port-short-circuit: Triggered when a short circuit is detected on a port.
thermal-shutdown: Triggered when the PSE chip overheats. The switch will stop supplying
power in this case.
Step 3 end
Return to Privileged EXEC Mode.
Step 4 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to configure the switch to enable all PoE traps:
Switch#configure
Switch(config)#snmp-server traps power
Switch(config)#end

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
