TP-Link T2600G Series User Manual

Configuring DDM (Only for Certain Devices) DDM Configuration
User Guide
129
■ Configuring the Voltage Threshold
Figure 2-3 Configure Voltage Threshold
Follow these steps to configure DDM‘s voltage threshold:
1) In the Voltage table, select one or more SFP ports to configure voltage threshold on
the SFP ports.
High Alarm Specify the high voltage threshold for the alarm. When the operating parameter
rises above this value, action associated with the alarm will be taken. The valid
values are from 0 to 6.5535.
Low Alarm Specify the low voltage threshold for the alarm. When the operating parameter
falls below this value, action associated with the alarm will be taken. The valid
values are from 0 to 6.5535.
High Warning Specify the high voltage threshold for the warning. When the operating parameter
rises above this value, action associated with the warning will be taken. The valid
values are from 0 to 6.5535.
Low Warning Specify the low voltage threshold for the warning. When the operating parameter
falls below this value, action associated with the warning will be taken. The valid
values are from 0 to 6.5535.
LAG Displays the LAG number which the port belongs to.
2) Click Apply.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
