Configuring Private VLAN Configuration Example
User Guide
285
Figure 3-2 Creating Primary VLAN 6 and Secondary VLAN 5
2) Choose the menu L2 FEATURES > VLAN > Private VLAN and click to load the
following page. Create primary VLAN 6 and secondary VLAN 7, select Community as
the Secondary VLAN Type. Add promiscuous port 1/0/2 and host port 1/0/11 to private
VLAN.
