TP-Link T2600G Series User Manual

User Guide 488
Configuring L2PT L2PT Configuration
Step 2 l2protocol-tunnel
Enable the L2PT feature globally.
Step 3 interface { fastEthernet
port | range fastEthernet port-list | gigabitEthernet port | range
gigabitEthernet
port-list | ten-gigabitEthernet port | range ten-gigabitEthernet port-list |
port-channel port-channel-id | range port-channel port-channel-id-list }
Enter interface configuration mode.
Step 4 l2protocol-tunnel type uni { 01000ccccccc | 01000ccccccd | gvrp | stp | lacp | all } [
threshold
threshold ]
Configure the port as a UNI port, specify the Layer 2 protocol types of the packets that can
be transparently transmitted on the port, and set the threshold for packets-per-second
accepted for encapsulation on the UNI port.
01000ccccccc: Enable protocol tunneling for the packets with their destination MAC
address as 01000CCCCCCC, which includes CDP, VTP, PAgP and UDLD.
01000ccccccd: Enable protocol tunneling for the PVST+ packets with the destination MAC
address as 01000CCCCCCD.
gvrp: Enable protocol tunneling for the GVRP packets.
stp: Enable protocol tunneling for the STP packets.
lacp: Enable protocol tunneling for the LACP packets.
all: All the above Layer 2 protocols are supported for tunneling.
threshold: Set a threshold which determines the maximum number of packets to be
processed for the specified protocol on the port in one second. When the threshold is
exceeded, the port drops the specified Layer 2 protocol packets. The valid values are from
1 to 1000 (packets/second). 0 indicates that the threshold feature is disabled.
Step 5 exit
Return to global configuration mode.
Step 6 interface { fastEthernet
port | range fastEthernet port-list | gigabitEthernet port | range
gigabitEthernet
port-list | ten-gigabitEthernet port | range ten-gigabitEthernet port-list |
port-channel port-channel-id | range port-channel port-channel-id-list }
Enter interface configuration mode.
Step 7 l2protocol-tunnel type nni
Configure the port as an NNI port.
Step 8 show l2protocol-tunnel global
Verify the global L2PT configuration.
Step 9 show l2protocol-tunnel interface [ fastEthernet
port | gigabitEthernet port | ten-
gigabitEthernet
port | port-channel port-channel-id ]
Verify the L2PT configuration of the port or LAG.

TP-Link T2600G Series Specifications

General

Model	T2600G Series
Layer	Layer 2+
Type	Managed
Uplink Ports	4 x Gigabit SFP slots
VLAN	4K VLANs
QoS	8 priority queues
Management	Web-based GUI, CLI, SNMP, RMON
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Interface	RJ45
L2 Features	STP, RSTP, MSTP, LACP, IGMP Snooping
L3 Features	Static Routing
Security	802.1X, Port Security, DHCP Snooping, IP Source Guard, DoS Defend, ARP Inspection, SSH, SSL, ACL
MAC Address Table	16K
Jumbo Frame	9KB
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% RH non-condensing
Storage Humidity	5% to 90% non-condensing
