User Guide 808
Configuring ACL ACL Configuration
dscp-value:
Specify the DSCP value between 0 and 63.
tos-value:
Specify an IP ToS value to be matched between 0 and 15.
pre-value:
Specify an IP Precedence value to be matched between 0 and 7.
frag {enable | disable}: Enable or disable matching of fragmented packets. The default is
disable. When enabled, the rule will apply to all fragmented packets and always permit to
forward the last fragment of a packet.
Note: frag {enable | disable} is not available T2600G-18TS.
protocol:
Specify a protocol number between 0 and 255.
s-port-number:
With TCP or UDP configured as the protocol, specify the source port number.
s-port-mask:
With TCP or UDP configured as the protocol, specify the source port mask with 4
hexadacimal numbers.
d-port-number:
With TCP or UDP configured as the protocol, specify the destination port
number.
d-port-mask:
With TCP or UDP configured as the protocol, specify the destination port mask
with 4 hexadacimal numbers.
tcpflag:
With TCP configured as the protocol, specify the flag value using either binary
numbers or * (for example, 01*010*). The default is *, which indicates that the flag will not be
matched.
The flags are URG (Urgent flag), ACK (Acknowledge Flag), PSH (Push Flag), RST (Reset Flag),
SYN (Synchronize Flag) and FIN (Finish Flag).
time-range-name:
The name of the time-range. The default is No Limit.
Step 4 end
Return to privileged EXEC mode.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to create IP ACL 600, and configure Rule 1 to permit
packets with source IP address 192.168.1.100:
Switch#configure
Switch(config)#access-list create 600
Switch(config)#access-list ip 600 rule 1 permit logging disable sip 192.168.1.100 sip-
mask 255.255.255.255
Switch(config)#show access-list 600
IP access list 600 name: ACL_600
rule 1 permit logging disable sip 192.168.1.100 smask 255.255.255.255
Switch(config)#end
Switch#copy running-config startup-config
