User Guide 838

Configuring ACL Configuration Example for ACL

Figure 3-27 Configuring Rule 5

5) Configure rule 15 to deny all the packets except the packet with source MAC address

6C-62-6D-F5-BA-48, and destination port TCP 23 (Telnet service port).
