Issue 3.0
SV9100 System Hardware Manual 2-29
6.2 Power Requirements
A dedicated 100VAC/120VAC/220VAC/230 – 240VAC 50Hz/60Hz circuit located
within seven feet of the chassis is required. A separate dedicated outlet for each
chassis should be installed.
6.2.1 Power Supply Specifications
AC Power Supply:
Dedicated 15 Amp circuit
Power Requirements: 120VAC @ 15A Controlling/Base Chassis
Power Consumption: Base Chassis = 263VA,
Expansion Chassis = 263VA, total 1052VA
Input Voltage: 90VAC to 264VAC
(Rated Voltage: 100VAC/120VAC/220VAC – 240VAC)
Frequency: 47Hz – 63Hz (Rated frequency: 50/60Hz)
Phase and Wire: Single Phase, 2 Line + PE Type
Grounding Requirements: No. 14 AWG copper wire
Feeding Voltage: D
term
/OPX/DID: -48V
SLT: 25mA / -28V
With input voltage of 120VAC and with full load conditions:
Output Power: Base chassis=130W, Expansion chassis=130W,
total 520W
AC Input I: Base chassis = 2.19A, Expansion chassis=2.19A, total
8.76A
Table 2-19 Cabling Requirements
Connected Equipment Cable
Music on Hold and Background Music Sources Hi-Fi Shielded Audio Cable
External Amplifier Hi-Fi Shielded Audio Cable
ITL Cabling Cat 5 Straight Data Network Cable
– 328.1 ft (100m) maximum
distance
IP Video Doorphone Maximum 100m (by LAN cable)
Double Pole/Neutral Fusing
(power supply fuses are located at both the L and N side).
