Issue 3.0
9-140 Installing SV9100 Optional Equipment
23. Install the new keypad panel supplied with the PSA-L UNIT.
24. Install both plastic panels to the front of the multiline terminal (refer to
Figure 9-129 Install Plastic Panels).
25. Connect the line cord to the adapter.
26. Connect the user system (KTS or PBX) cable.
27. If required, remove the side panel from the original cradle unit.
Figure 9-128 Install Numbered Keypad
Figure 9-129 Install Plastic Panels
