Issue 3.0
5-34 Installing DT Series Digital and IP Multiline Terminals
3.1.7 ITL-12DG-3 (BK) TEL
This IP value multiline terminal has 12 line keys and is available in black
only. The terminal features:
USB Connection (USB 2.0, 5V/500mA supply)
Modular design
Four-step adjustable base
Full-duplex speaker phone
Protection button
Seven-color LED for incoming calls
Menu/Softkey operation provided on the LCD
Backlit Numbered Keypad for easy viewing
Full-duplex handsfree operation
224 x 96 dot matrix gray scale backlit LCD
IEEE 802.3at Type 1 compliant
XML open interface
10 Base-T/100 Base-TX/1000 BASE-T network interface
Figure 5-21 ITL-12DG-3 TEL
