NEC Univerge SV9100 - Figure 6-35 Attach Bluetooth Cradle to the Multiline Terminal; Figure 6-36 Grooved Cutout for Connecting Cable

Issue 3.0
6-30 Installing SV9100 Cordless Telephones
10. Insert the cradle connecting cable of the Bluetooth Cradle (BTC) into
the unit connector.
11. Fit the projections on the side of the Bluetooth Cradle into the guide
holes on the side of the terminal and pull toward you (Figure 6-35
Attach Bluetooth Cradle to the Multiline Terminal) until the unit snaps
into place.
12. Attach the side panel to the Bluetooth Cradle.
13. Press the connecting cable into the grooved cutout.
Figure 6-35 Attach Bluetooth Cradle to the Multiline Terminal
Figure 6-36 Grooved Cutout for Connecting Cable
