NEC Univerge SV9100 - Figure 5-68 Remove Side Panel from Multiline Terminal; Figure 5-69 Ribbon Cable Connector

Issue 3.0
SV9100 System Hardware Manual 5-69
2. Pry the side panel from the multiline terminal.
3. Remove the screw (refer to Figure 5-68 Remove Side Panel
from Multiline Terminal).
4. Carefully, return the multiline terminal to the buttons side up.
5. Remove the Softkeys and Line Key kit from the telephone.
6. Gently lift the small black bar to open the ribbon cable
connector.
Figure 5-68 Remove Side Panel from Multiline Terminal
Side Panel
Screw
Figure 5-69 Ribbon Cable Connector
Lift
Here
