Issue 3.0
5-68 Installing DT Series Digital and IP Multiline Terminals
5.2.3 8LKI (LD)-L UNIT (BK/WH)
Provides eight additional line keys to DT700 Series (ITL) DESI-Less
terminals. The unit features:
Mounts directly to top of terminal
Supports Desi-Less 2 LCD panels
Eight line keys by four pages
5.2.3.1 Installing the 8LKI (LD)-L UNIT
1. Turn multiline terminal upside down.
Only one 8LKI (LD)-L UNIT can be attached to the ITL
multiline terminal.
Figure 5-67 8LKI (LD)-L UNIT
To prevent possible damage to the 8LKI (LD)-L
UNIT or the ITL multiline terminal during
installation or removal, disconnect the line
cord/LAN cable and the AC/DC adapter from the
ITL multiline terminal.
To Next Page
