Issue 3.0
SV9100 System Hardware Manual 6-21
3.2.4 Installing the Repeater
1. Hold the repeater in its final location, and mark the center of the top
edge.
2. From the edge mark, measure down approximately 1-1/2 inches, and
mark the screw location.
3. At the screw location, use a 3/16ths drill bit to make a pilot hole
approximately one inch deep.
4. Place the wall anchor into the pilot hole and tap it gently with a
hammer until the anchor is flush with the wall.
5. Insert the mounting screw into the anchor, leaving approximately 1/4
inch space between the screw head and the wall.
6. Put the repeater over the screw head and slide it down into place.
7. Connect the repeater to the 120V AC power outlet.
3.2.5 Multiple Repeater Systems
You can register up to six repeaters to one base as long as the repeaters
are a minimum of 30 feet apart. Remember that the signal can cross
through walls and floors.
3.2.5.1 Incorrect Installation
Figure 6-27 Incorrect Installation on page 6-22 illustrates
repeaters that are incorrectly installed.
Be sure the wall material can hold the weight of the repeater.
Never install a repeater in damaged or decaying wall material.
