Issue 3.0
SV9100 System Hardware Manual 3-63
4.2.2.2 Wall Mounting the CHS2UG B-US with the CHS2UG B
Small Batt Box
To install the CHS2UG B SMALL BATT BOX refer to section 8.3
Installing the CHS2UG B SMALL BATT BOX on the 9.5”
CHS2UG B Chassis on page 3-104
1. Align the bracket halves (refer to Figure 3-72 Wall
Mounting Brackets (Option 2)).
2. Turn the brackets upside down and remove four screws
(refer to Figure 3-78 Brackets (Small Batt Box) on page
3-64).
Figure 3-77 Wall Mounting (Small Batt Box)
