Issue 3.0
3-20 Installing the SV9100 Chassis
3.3.5 Install AC Power Cords on 19” Chassis
1. Locate the supplied AC power cord and attach to the AC Inlet located
on the back of the Controlling Chassis.
Figure 3-23 19” Chassis Grounding Lug (Multiple-Chassis)
FG Lugs
Electrical
Service
Ground
Figure 3-24 Install the AC Power Cord
AC Inlet
CHS2UG-US
