Issue 3.0
SV9100 System Hardware Manual 9-149
17. Install the cable from the optional external AC adapter (refer to Figure
9-143 AC to DC In Connection).
18. Cable installation for the GBA-L UNIT complete (refer to Figure 9-144
GBA-L UNIT Installed).
IMPORTANT
The AC Adapter (AC-L UNIT) must be ordered
separately.
Figure 9-143 AC to DC In Connection
Figure 9-144 GBA-L UNIT Installed
