Issue 3.0
6-36 Installing SV9100 Cordless Telephones
4. Turn multiline terminal upside down.
5. Lower the tilt leg to the first position (refer to Figure 6-32 Separate Tilt
Leg from Leg Support).
6. Hook the wall mount holes (C and D) on the back of the terminal on
wood screws (c and d) installed.
Figure 6-45 Separate Tilt Leg from Leg Support
Figure 6-46 Wall Mounting the Terminal
