NEC Univerge SV9100 - Figure 5-107 Attach WM-L UNIT Using Screws; Figure 5-108 Plugging in Line Cord

Issue 3.0
SV9100 System Hardware Manual 5-95
2. Plug one end of the line cord into the wall receptacle. Leave
about eight inches of cord and bundle the rest.
3. Plug the opposite end of the line cord into the multiline
terminal as illustrated in Figure 5-108 Plugging in Line Cord.
Figure 5-107 Attach WM-L UNIT Using Screws
Figure 5-108 Plugging in Line Cord
