Issue 3.0
SV9100 System Hardware Manual 5-93
5.2.10 LCD (BL)-L UNIT (BK/WH)
The LCD (BL)-L UNIT is an optional LCD unit for modular terminals and
supports the backlit LCD feature (DT300 Series only).
5.2.11 LCD (BL)-Z UNIT (BK/WH)
The LCD (BL)-Z UNIT is an optional LCD unit for modular terminals and
supports the backlit LCD feature (DT400 Series only).
5.2.12 PANEL( )-L UNIT
Optional plastic color side panels allow users to customize the ITL/DTL
terminals. A variety colors are available for the Base (all), VLCD (Value
LCD) and SLCD (Sophi LCD) terminals (refer to Chapter 1, Table 1-10
DT300/DT700 Series Optional Equipment List on page 1-10).
 Right and Left side panels are not interchangeable.
Figure 5-103 LCD (BL)-L UNIT
Figure 5-104 LCD (BL)-Z UNIT
Figure 5-105 PANEL( )-L UNIT
