NEC Univerge SV9100 - Figure 3-52 Attachment Locations of Cable Support Bracket

Issue 3.0
SV9100 System Hardware Manual 3-45
9. The cable support bracket can be installed any of the four corners of
the 19” chassis (refer to Figure 3-52 Attachment Locations of Cable
Support Bracket on page 3-45).
10. Connect the ground wire to all chassis. Refer to 3.3.3 Install
Grounding on 19” Chassis on page 3-19 for complete details on
grounding the system.
11. Refer to 3.3.5 Install AC Power Cords on 19” Chassis on page 3-20 to
continue installation of the chassis or, Chapter 6 paragraph 2.1
Installation and Safety Precautions on page 4-4 for installation of
blades.
Figure 3-52 Attachment Locations of Cable Support Bracket
