5.6.3 LED Indications
LED indications for the GCD-PRTA are listed in Table 4-32 GCD-PRTA LED
Indications. Each LED is listed with its associated function and LED and
Operational status.
Refer to Figure 4-26 GCD-PRTA Blade on page 4-75 for the location of the
LEDs on the blade.
Table 4-32 GCD-PRTA LED Indications
LED Indication
Operation Status Remarks
Live LED
(Green)
Busy LED (Red)
On On System Initializing
–
Flash (1s) On The assignment of the unit is refused.
When you exceed the system
capacity.
When the main software version is
not matched.
Flash (1s) Trouble found during self-diagnostics.
–
Flash
(100ms)
On
Normal
Operation
A Channel is busy (use
another from CH1 ~ CHx).
–
Off
All channels are idle. –
Off
On
Unit Busy
A Channel is busy (use
another from CH1 ~ CHx).
–
Off
All channels are idle. –
Flash 80ms (On/
Off) x 3/400ms
Off
Downloading firmware.
–
