Issue 3.0
9-148 Installing SV9100 Optional Equipment
15. Install the NEC provided power cable (refer to Figure 9-141 DC
Power Connection).
16. Connect the Core then plug in the Network connection cable (refer to
Figure 9-142 LAN(=) Connection).
Figure 9-141 DC Power Connection
Figure 9-142 LAN(=) Connection
