NEC Univerge SV9100 - Figure 5-75 Removing the DESI Sheet; Figure 5-76 Removing the Line Key Placeholder

Issue 3.0
SV9100 System Hardware Manual 5-73
4. Lift and remove the DESI sheet.
5. Press the right end of the Line Key placeholder and lift to
remove (refer to Figure 5-76 Removing the Line Key
Placeholder).
Figure 5-75 Removing the DESI Sheet
DESI Sheet
Figure 5-76 Removing the Line Key Placeholder
