NEC Univerge SV9100 - Figure 5-34 Installing the Line Cord (DT300)

Issue 3.0
5-46 Installing DT Series Digital and IP Multiline Terminals
4.1.2 Connecting the Line Cord
Confirm the location of the line connector on the bottom of the multiline
terminal. Then, connect the line cord to the multiline terminal using the
steps shown below.
4.1.2.1 Line Cord Connection DT300
1. Install the modular plug of the Line Cord into the Line
Connector at the back of terminal. Push until it snaps into
place. Refer to Figure 5-34 Installing the Line Cord (DT300).
Figure 5-33 Installing the Handset (DT400)
Figure 5-34 Installing the Line Cord (DT300)
