Issue 3.0
SV9100 System Hardware Manual 2-45
Table 2-23 Tone Patterns
System Tone
(Fixed)
Frequency (Hz)
(Fixed)
Intermit
(Default)
Cycle
Busy Tone 480/620 60 IPM
Call Waiting Tone 440 60 IPM
Second Dial Tone 350/440 120 IPM
Howler Tone
2400 Modulation
(16 Hz)
Continuous
Internal Dial Tone 350/440 Continuous
Internal Ringback Tone 440/480
1 sec On
2 sec Off
LCR Dial Tone 440 Continuous
Reorder Tone 480/620 120 IPM
Service Set Tone 440 Continuous
Special Dial Tone 440 240 IPM
Tone Burst 1 Tone 440 Continuous
Tone Burst 2 Tone 620 Continuous
Tie/DID Ringback Tone 440/480
2 sec On
4 sec Off
Camp-On Tone
Call Alert Notification
Attendant Tone Override
440 Continuous
DIT Alert Tone 480/620 Continuous
Call Forward Alert Tone
Call Forward
Configuration Tone
350/440 120 IPM
0.5 sec
0.5 sec
0.5 sec
0.5 sec
0.25 sec
0.25 sec
1 sec
2 sec
0.25 sec
0.25 sec
0.125 sec
0.125 sec
1 sec
1 sec
2
s
e
c
4
s
e
c
0.7 sec
0.5 sec
0.25 sec ON x 2~3
