Issue 3.0
SV9100 System Hardware Manual 4-71
Table 4-29 GPZ-2BRIA RJ-61 Cable Connector Pin-Outs
RJ-61 Cable Connector – CN7, CN8
T-Bus Connection
Pin No. Connection
1—
2—
3TA
4RA
5RB
6TB
7—
8—
