Issue 3.0
4-112 Installing the SV9100 Blades
LAN Connector – (RJ45)
(1000Base-T)
Pin No. Connection
1BI_DA+
2BI_DA-
3BI_DB+
4BI_DC+
5BI_DC-
6BI_DB-
7BI_DD+
8BI_DD-
Table 4-44 GCD-SVR2 LAN Connector Pin-Outs (Continued)
