SV9100 System Hardware Manual 8-1
Chapter 8
UNIVERGE
®
SV9100
Installing SV9100 Conference
Solutions
SECTION 1 GENERAL DESCRIPTION
Conferencing solutions provide premium, full-duplex audio to small conference
rooms as a single unit or to larger rooms when expanded by up to three units that
also expand microphone access and loudspeaker coverage.
SECTION 2 NEC SIP CONFERENCE MAX
The NEC SIP Conference Max expandable conferencing telephone provides
premium, full-duplex audio to small conference rooms as a single unit and to larger
rooms as an expanded system. Up to four SIP Conference Max units can be linked,
expanding not only microphone coverage but loudspeaker coverage and control
access as well. This creates even distribution of sound for a more natural
communications experience.
2.1 Installation
1. Connect the cable from the Link Out on the base unit to the Link In jack on
the conferencing pod.
Do Not plug a laptop or PC into the Link Out jack on the base unit
or conferencing pod, severe electrical damage could occur.
