SV9100 System Hardware Manual 9-1
Chapter 9
UNIVERGE
®
SV9100
Installing SV9100 Optional Equipment
SECTION 1 GENERAL INFORMATION
This chapter provides information for installing optional equipment, such as
PGD(2)-U10 ADPs, background music, door boxes, DSS consoles, D
term
VSR,
external paging as well as other handsets, recording devices and adapters on the
SV9100 digital and IP telephones.
SECTION 2 PGD(2)-U10 ADP
2.1 Using a PGD(2)-U10 ADP
The PGD(2)-U10 ADP provides two circuits which allow connection to external
terminals such as:
Door Box (eight maximum per system)
External Speaker (eight maximum with PGD(2)-U10 ADPs [with amplifier], one
on the GCD-CP10 [no amplifier])
External Music Source (external MOH) (96 maximum per system)
External Recording System (96 maximum per system)
External Ringing
The system allows a maximum of 56 PGD(2)-U10 ADPs to be installed (48 for ACI
ports [external MOH or external recording system], four for Door Boxes, and four
for Paging). The PGD(2)-U10 ADPs also provides multi-purpose controls. These
control relays can be used for controlling the external amplifier, external music
source and door lock control with the use of a Door Box. The system allows up eight
general purpose relays with the PGD(2)-U10 ADPs (four relays on each
PGD(2)-U10 ADP) and one on the GCD-CP10 for a maximum of nine.
