Issue 3.0
SV9100 System Hardware Manual 9-163
Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2,
EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN
61000-4-11)
Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and
Canada), CE Marking (Europe)
California Best Management Practices Regulations for Perchlorate Materials: This
Perchlorate warning applies only to products containing CR (Manganese Dioxide)
Lithium coin cells. “Perchlorate Material-special handling may apply, refer to
www.dtsc.ca.gov/hazardouswaste/perchlorate.”
SECTION 16 IP VIDEO DOORPHONE
IP Video Doorphone tables has been saved in: SV9100_IP Video Doorphone Equip -
SAVE file
16.1 Connection Image
The IP Video Doorphone (IP3NE-IPCDH) connects with the IPLE via the PoE
Switch(IEEE802.3af). The system can support a maximum of eight doorphones,
which are shared between the video and 2PGDAD doorphones.
For more information refer to:
❍ UNIVERGE SV9100 IVR – Appointment Reminder Server
Configuration Guide.
❍ UNIVERGE SV9100 IVR – Broadcast Server Configuration
Guide
The IP Video Doorphone port requires both a door phone and SIP
extension port. If the extension port is not available, the IP Video
Doorphone can not be connected.
