2-6 SV9100 System Specifications
Analog Trunks (COT)
16 40 88 136 184
Tot al 40 0
BRI
16 40 88 136 184
PRI (1.5M)
48 96 192 288 384
IP Trunk (SIP)
400
DTMF Receivers
80 144 144 144 144 *2
VoIP Channels
256 256
Voice Mail Channels on CPU
16 channels 16
Modem
1 channel 1

1 = For-law countries 104 timeslots per chassis are assigned the G.711 PCM communications (e.g., voice
communications) and 7 timeslots per chassis are assigned for the Data communications (e.g., HDLC over ISDN). Thus
the simultaneous data communications are limited up to seven per chassis.

2 = An additional 64 DTMF Receivers are available when the GPZ-BS10 is installed.
 If using Caller ID to analog trunks and DSP resources are set to common, DSP resources will only be used for analog
trunks and not analog stations.
Table 2-2 SV9100 9.5” Gateway and 19” Maximum System Capacities – Trunks/Ports/Channels (Continued)
Number of:
9.5”
Chassis
19” Chassis
System
Maximum
x 1
(CPU + 2
Slots)
x 1
(6 Slots)
x 2
(12 Slots)
x 3
(18 Slots)
X4
(24 Slots)
