Conversion Tasks
Issue 2.1 June 2006 1125
Installing the new circuit packs
!
Important:
Important: In some cases, you might need to remove an existing circuit pack from a slot
before you install the new circuit pack. Remove these existing circuit packs last,
after you install, cable, and administer all the new circuit packs that go into empty
slots. To remove existing circuit packs, follow the procedures in Disabling PNC
duplication, if necessary on page 1133 and Removing fiber-related
administration on page 1134.
Tip:
Tip: The TN2312BP, TN2602AP, and TN799D circuit packs all support hot-plug-in.
That is, they can be inserted into a live system without disrupting call processing.
MCC1 EPN containing three
PNs
● Tone Clock slot
(A00)
● B02
● D02 (single control)
● E02 (duplicated
control)
Control duplication is not
supported with three PNs.
D01 (duplicated control)
MCC1 EPN containing four PNs
● Tone Clock slot
(A00)
● B02
● C02
● D02 (single control)
● E02 (duplicated
control)
Control duplication is not
supported with four PNs
D01 (duplicated control)
MCC1 EPN containing five PNs
● Tone Clock slot
(A00)
● B02
● C02
● D02
● E02
Control duplication is not
supported with five PNs
IPSI slot locations (continued)
Carrier or Gateway
Slot Number
Primary Secondary, if duplicated
control, for S8700 series
only
2 of 2
