Migrating an Avaya IP600/S8100 to an S8700-Series Media Server with IP-PNC
858 Upgrading, Migrating, and Converting Media Servers and Gateways
Replacing the processor circuit pack
To replace the processor circuit pack:
1. Remove the entire processor circuit pack.
2. Place the circuit pack in an antistatic carrier or bag. You want the circuit pack intact if you
need to back out of the migration.
3. Remove the octopus cable from the connector that is associated with slot 2 on the
backplane.
4. Install the IPSI adapter to the connector that is associated with slot 2 on the backplane.
5. Install the maintenance cable onto the 9-pin D-sub connector on the adapter. This cable is
for emergency transfer and "auxsig" signal.
Note:
Note: The TN2312BP Internet Protocol Server Interface (IPSI) circuit pack takes only
one slot.
6. Insert the TN2312BP Internet Protocol Server Interface (IPSI) circuit pack into slot 2.
7. Attach the new label above the circuit pack slots.
Replacing the TN799C C-LAN circuit pack
If you need to replace the TN799C C-LAN circuit pack:
1. Remove the TN799C Control-LAN (C-LAN) circuit pack.
2. Place the circuit pack in an antistatic carrier or bag. You might need to reinstall this circuit
pack if you must stop the migration.
3. Insert the new TN799DP C-LAN circuit pack into the same slot.
4. Replace the 259A adapter and CAT3 cable on the connector panel.
5. Use the Amphenol adapter that you used for the TN799 circuit pack and a CAT5 cable.
