Migration tasks
Issue 2.1 June 2006 535
13. Assign the switch ID and the cabinet ID to the TN2312BP Internet Protocol Server Interface
(IPSI) circuit pack that you just inserted. For more information, see Assigning IP addresses
to the IPSI circuit packs on page 537.
Note:
Note: For consistency, use the ribbon in the front for connectivity. Do not use ICCC.
Connecting the CAT5 cables to the IPSI circuit packs
Note:
Note: For a connectivity guide, see Quick Start for Hardware Installation: Avaya S8500
Media Server (555-245-701) or Quick Start for Hardware Installation: Avaya
S8700 Series Media Server (555-245-703) and Job Aid, Cabling Guide - MCC1
and SCC1 Media Gateway (555-245-771).
To connect the CAT 5 cables to the IPSI circuit packs:
● Connect the green CAT5 cable to the IPSI in the A carrier.
Installing Expansion Interface circuit packs
You must replace any expansion interface circuit packs in the PPN.
● If the existing PPN has TN776 or TN570 Expansion Interface circuit packs, you must
replace them with a TN570B Expansion Interface vintage 7 or later circuit pack.
● If this system includes an Enterprise Survivable Server (ESS), replace the circuit packs
with a TN570D or later Expansion Interface circuit pack.
To install the Expansion Interface circuit packs:
1. Remove the existing circuit pack.
2. Place the circuit pack in an antistatic carrier or bag.
3. Insert the TN570B Expansion Interface vintage 7 or later circuit pack into the EXPN INTFC
slots (A01, A02).
4. Repeat Steps 1 and 2 for each PN that does not contain TN570B Expansion Interface
vintage 7 or later circuit packs.
