Field Description
LineCard Number of the line card that contains
information on ACL VLAN groups
Portpipe The hardware path that packets follow
through a system for ACL optimization
CAM-Region Type of area in the CAM block that is
used for ACL VLAN groups
Total CAM space Total amount of space in the CAM
block
Used CAM Amount of CAM space that is currently
in use
Available CAM Amount of CAM space that is free and
remaining to be allocated for ACLs
Example 1:
Output of the
show cam-
usage
Command
Dell#show cam-usage
Linecard|Portpipe| CAM Partition | Total CAM | Used CAM
|Available CAM
========|========|=================|=============|
=============|==============
1 | 0 | IN-L2 ACL | 1008 | 320
| 688
| | IN-L2 FIB | 32768 | 1132
| 31636
| | IN-L3 ACL | 12288 | 2
| 12286
| | IN-L3 FIB | 262141 | 14
| 262127
| | IN-L3-SysFlow | 2878 | 45
| 2833
| | IN-L3-TrcList | 1024 | 0
| 1024
| | IN-L3-McastFib | 9215 | 0
| 9215
| | IN-L3-Qos | 8192 | 0
| 8192
| | IN-L3-PBR | 1024 | 0
| 1024
| | IN-V6 ACL | 0 | 0
| 0
| | IN-V6 FIB | 0 | 0
| 0
| | IN-V6-SysFlow | 0 | 0
| 0
| | IN-V6-McastFib | 0 | 0
| 0
| | OUT-L2 ACL | 1024 | 0
| 1024
| | OUT-L3 ACL | 1024 | 0
| 1024
| | OUT-V6 ACL | 0 | 0
| 0
1 | 1 | IN-L2 ACL | 320 | 0
| 320
| | IN-L2 FIB | 32768 | 1136
| 31632
| | IN-L3 ACL | 12288 | 2
